Project Infrastructure

Mine facilities being developed by the Company

Overview of mine facilities and infrastructure developed by ETHIOPOTASH to reach production

ETHIOPOTASH is supported by the very best of technical experts, leaders in their fields, to design its mining operations (solution mining, evaporation ponds and brackish wells), freshwater wells, process plant, supporting infrastructure and port terminal

Project Execution Plan

Specifications approved

Updated CAPEX

Project
Infrastructure

Design
Advisor

Solution mining

  • 42 caverns of 30m radius to be initiated and replaced annually

Ponds

  • 55 ponds representing a combined surface of 5.5km2

Process plant

  • A wet plant and a dry plant to treat product from crushing to load-out

Water wells

  • 21 wells to be drilled, located in a 5km radius around the Dallol site

Terminal

  • Storage area for 75,000 MT with ability to load ship at 1,200 MT/h

Other

  • Permanent workers’ camp
  • Administration building
Solution mining Ponds Process plant Water wells Terminal Other
Project Infrastructure 42 caverns of 30m radius to be initiated and replaced annually 55 ponds representing a combined surface of 5.5km2 A wet plant and a dry plant to treat product from crushing to load-out 21 wells to be drilled, located in a 5km radius around the Dallol site Storage area for 75,000 MT with ability to load ship at 1,200 MT/h
  • Permanent workers’ camp
  • Administration building
Design Advisor

Major project infrastructure developed by external stakeholders

Overview of key third party infrastructure investments tailored for the projects needs

Power lines

  • The Dallol Project will require a 35MW electricity power supply
  • Connection to the national grid has been chosen as best option
  • A 180km and 230 kV power transmission line, funded by the African Development Bank, is completed by Ethiopian Electric Power (“EEP”) to connect the Dallol Project to the existing grid at Mekele, with a local sub-station at Dallol with last finishing works to be done
  • Ethiopia power generation is mainly provided by clean hydro power, supplemented by wind
  • The construction of the transmission line and sub station for US $ 56M is funded by AfDB

Lowland roads

  • Ethiopian government has constructed 486km lowland export road to allow for potash trucking from Dallol to Port de Tadjoura
  • The export lowland road is more than 80% completed.

Port

  • Final product to be exported from the newly built port of Tadjoura in neighboring Djibouti
  • The 40 hectare port which is dedicated to potash exports, was inaugurated in 2017
  • Total investment to build the port amounted to $78 M by Djibouti government
  • Storage terminal to be built for potash
  • Port authority to provide shiploader and a conveyor along with major utilities to the site boundary, including electric power, potable water and wastewater facilities

Proven third party commitment to enable project operations and product exports
